Compressed Air System

Air Impact Wrench

NC-8236-6 Contact Us

Twin hammer type.

Exceptional Power-to-Weight Ratio: Delivers a massive 2,441 Nm (1,800 ft-lb) max torque in a lightweight 4.6 kg frame—power without the bulk.

High-Speed Productivity: Features a 7,000 RPM free speed to accelerate task completion and maximize workshop throughput.

Ergonomic Operator Comfort: Engineered to reduce vibration and hand fatigue, ensuring safety and comfort during long shifts.

Industrial-Grade Durability: Ideal for the most demanding sectors, including Railways, Shipbuilding, and Heavy Fleet Maintenance.

360° Swivel Inlet. Tangle-Free: 360° swivel air inlet prevents hose tangles and body interference.

Download

SPECIFICATIONS


Square Drive
1"

Torque Range
200-1600 (FT-LB) / 271-2170 (Nm)

Max Torque
1800 (FT-LB) / 2441 (Nm)

No Load Speed
7000 (R.P.M)

Avg. Air Consumption
7.0 (CFM) / 198 (L/min)

Air Pressure
90 (PSI) / 6.3 (bar)

Overall Length
21" / 520 (mm)

Net Weight
4.6

Net Weight
10.1

Air Hose
1/2"

Sound Pressure
98 (dBA)

Vibration Level
9.0 (m/s²)

Bolt Capacity
1-1/16" / 27 (mm)

Air inlet
3/8"

Nut
41 (mm)
