Square Drive
1/2"
BACK
Recommend
Compressed Air System
Recommend
Compressed Air System
Air Impact Wrench NC-4232Q
SPECIFICATIONS
Torque Range
100-400 (FT-LB) / 136-542 (Nm)
Max Torque
550 (FT-LB) / 746 (Nm)
Free Speed
10000 (R.P.M)
Avg. Air Consumption
4.0 (CMF) / 113 (L/min)
Air Pressure
90 (PSI) / 6.3 (bar)
Overall Length
4-3/4" / 120 (mm)
Net Weight
1.38
Net Weight
3.0
Air Hose
3/8"
Sound Pressure
83 (dBA)
Vibration Level
3.7 (m/s²)
Bolt Capacity
5/8" / 16 (mm)
Air inlet
1/4"
FEATURES
+ Sophisticated and powerful tool: m7’s most advanced composite mini air impact wrench that can use in narrow space.
+ Unbelievable light and compact with only 1.35kg
+ Quiet series: sound pressure only 83 Dba
+ “m7’s unique lazy design” that can operate forward/reverse switch with one hand.
+ Twin-hammer impact mechanism provides more torque power and stability, and balanced impact can reduce the vibration.
+ Ergonomic switch design well suited for operator’s hand that provides fingers with most comfortability and controllability.
+ m7’s unique shark fin shaped body design that creates an esthetics of speed and explosiveness.
