Air Impact Wrench
NC-4233Q Contact Us
+ Rotor blades attached with springs which prolong durability.
+ Shorter air inlet path to boost air efficiency
+ simple mechanism for easy maintenance
+ Air inlet 360 degree swivel.
+ Composite material light design
+ 3 setting forward power regulator for controlled run up.
Read More +
Download
SPECIFICATIONS
Torque Range
200-500 (FT-LB) / 271-678 (Nm)
Max Torque
850 (FT-LB) / 1152 (Nm)
No Load Speed
9000 (R.P.M)
Avg. Air Consumption
4.6 (CFM) / 132 (L/min)
Air Pressure
90 (PSI) / 6.3 (bar)
Overall Length
7-1/2" / 190 (mm)
Net Weight
2.10
Net Weight
4.6
Air Hose
3/8"
Sound Pressure
85.0 (dBA)
Vibration Level
4.4 (m/s²)
Bolt Capacity (Screw)
3/4" / 19 (mm)
Air inlet
1/4"
Bolt Capacity (Nut)
30 (mm)
