1/2" Drive Air Impact Wrench NC-4223
NC-4223 Contact Us
+ Equipped with Twin Hammer Impact mechanism.
+ Efficient & reliable torque output during operation.
+ Handle exhaust efficiently reduces the noise and directs air away from the working area.
+ NC-4223 is equipped with 2” extended anvil.
Read More +
Download
SPECIFICATIONS
Bolt Capacity (Screw)
5/8" / 16 (mm)
Torque Range
180-400 (FT-LB) / 244-542 (Nm)
Max Torque
600 (FT-LB) / 813 (Nm)
No Load Speed
6500 (R.P.M)
Avg. Air Consumption
4.2 (CFM) / 119 (L/min)
Air Pressure
90 (PSI) / 6.3 (bar)
Overall Length
9-1/4" / 232 (mm)
Net Weight
6.4
Net Weight
2.90
Air Hose
3/8"
Sound Pressure
91.0 (dBA)
Vibration Level
3.8 (m/s²)
Air inlet
1/4"
Bolt Capacity (Nut)
24 (mm)
